Description
DENALI GEN II CANsmart Controller for BMW R 1300 GS (2024+)
Upgrade your motorcycle's accessory control with the DENALI GEN II CANsmart Controller, designed for the BMW R 1300 GS. This intelligent plug-and-play accessory controller uses your motorcycle's CAN bus electrical system to simplify the installation and management of auxiliary lights, aftermarket horns, brake lights, and other electrical accessories.
With four independently configurable circuits, the GEN II CANsmart Controller provides advanced accessory integration and customizable lighting functions through the BMW WonderWheel or DENALI CANsmart Accessory Manager Software.
Key Features
-
Plug-and-Play Installation: Simplifies accessory wiring by integrating with the BMW CAN bus electrical system.
-
Four Independent Circuits: Connect and control up to four electrical accessories.
-
High Power Output: Each circuit supports up to 10 amps of continuous power, with a maximum total controller output of 30 amps.
-
High/Low Beam Sync: Automatically switch auxiliary lights between programmable intensity levels using the factory high-beam switch.
-
On/Off and Dimming Control: Independently operate and adjust two sets of compatible auxiliary lights.
-
Light Modulation: Configure auxiliary lights to modulate for increased visibility.
-
Flash-to-Pass: Activate auxiliary light flashing through the factory high-beam switch.
-
Turn Signal Integration: Configure compatible auxiliary lights to cancel on the corresponding side when a turn signal is activated.
-
Inverse Hazard Flashing: Configure auxiliary lights to flash in coordination with hazard lights for enhanced roadside visibility.
-
Plug-and-Play Horn Installation: Connect compatible high-power aftermarket horns, including the DENALI SoundBomb, without a separate horn relay harness.
-
Strobe with Horn: Configure auxiliary lights to flash when the horn is activated.
-
Smart Brake Technology: Uses vehicle speed and deceleration data to activate compatible auxiliary brake lights before the brake lever is applied, according to configured settings.
-
Customizable Brake Flash Patterns: Select from four brake-light flash patterns to improve rear visibility.
-
Switched 12V Power: Power compatible accessories that switch on and off with the ignition.
-
Delayed Power Shutdown: Configure the accessory circuit to remain powered for up to 30 seconds after the ignition is switched off.
Technical Specifications
-
Brand: DENALI
-
Product: CANsmart Controller GEN II
-
Compatible Motorcycle: BMW R 1300 GS (2024+)
-
Circuit Configuration: Four independently configurable circuits
-
Continuous Current Capacity: Up to 10A per circuit
-
Maximum Total Output: 30A continuous
-
Control Options: BMW WonderWheel and CANsmart Accessory Manager Software
-
Electrical System: BMW CAN bus
-
Accessory Compatibility: Compatible auxiliary lights, horns, brake lights, and other supported 12V accessories
